An outstanding solution with a traditional background
Stucco dating back to the application of mixed clay plasters in pre Biblical times has traditionally been used to decorate an protect buildings.
Embracing this concept with the latest technology and selected additives, Stoanz has specifically engineered the StoStucco, a plaster system on a stainless steel lath to meet the requirements of New Zealand's house owners, designers and specifiers. This unique and certified cladding solution offers a proprietary system to clad timber framed construction and gives architects the opportunity for an unlimited range of design concepts.
With a complex range of modern analytical equipment Sto pursues innovative technology that will meet ecologically acceptable standards. Using this approach Sto has developed a comprehensive range of facade plasters, finishing renders and cladding solutions to enable the specifiers to select an individual style to meet the project requirements.
Download brochures for your electronic reference or product library.
StoStucco Plaster System 20 mm
StoStucco is a BRANZ appraised plaster system based on the traditional New Zealand stucco net system. It incorporates a European stainless steel lath which is plastered with a lightweight mineral basecoat to provide a thick solid plaster base. As additional reinforcement, the StoArmat RFP mesh reinforcement plaster incorporating micro fibres and lightweight fillers provides the strength and durability. It is then finished with the perfect interlocking components; Stolit finishing render and Sto facade paint. Using modern technology with enhanced and well engineered materials this Stucco plaster system provides a strong and durable solution for a high performance facade.
Click on each of the layers below to see the components of the StoStucco Plaster System.
01
Timber Battens
25 mm rough sawn timber battens.
02
Substrate: Stainless steel lath
European manufactured and certified lath, which is light and strong, easy to shape and to install.
03
Basecoat: LevelLite 16 mm
Lightweight EPS bead mineral plaster with good build properties, water retention agents and machine application properties.
04
Reinforcement: StoArmat RFP
European manufactured and certified, strong, malleable, impact resistant, white reinforcing plaster in a pail. Contains a calibration grain ensuring correct mesh coat thickness. (No cement)
05
Plus: Sto European Mesh
Easy to install, meets the highest requirements for crack, stress and alkalinity resistance.
06
Finishing render: Stolit range
European manufactured and certified, organically bound, strong, hard wearing, impact resistant, pre-coloured finishing renders. (No cement)
Stolit K - (1mm/1.5mm/2mm/3mm)coloured finishing render. A range of coloured float finished self gauging granulated finishes.
Stolit MP & MP Natural - coloured finishing render. A range of coloured fine sponge finishes.
07
Coating:
StoColor Maxicryl - matt facade paint.
StoLastic Color - satin matt facade paint European manufactured and certified durable facade paints available in a full range of colours.
Click here to download the TDS.
Perfect Interaction
StoStucco system is cost-effective, solid, durable and offers greater flexural strength, higher impact resistance and faster installation than conventional stucco.
Incorporating a lath made from a stainless steel welded wire mesh into which an absorbent sheet of perforated chip paper is interwoven, it allows the applicator to work faster and more efficient. The perforations in the chip paper allow an optimal key of the mortar around the stainless steel wires.
Combining lightweight engineered mineral basecoat with technologically advanced fibre reinforcement plaster and elastomeric finishes, it creates a stucco cladding that is superior to the traditional, hand mixed applicator product.
Save Time and Costs
StoStucco's time and cost efficiency results not only from the quick and easy installation of the lath. Using a PFT Ritmo mixing pump the Sto System can be applied in a fraction of the usual application time.
Advantages:
- no pre mixing of plaster
- plaster mix of constant quality
- instant delivery to the work face
- ease of application
- saving labour costs
- saving time
Stolit: Coloured Finishing Renders
Stolit organic finishing renders are manufactured in Europe and certified around the world. They have been in successful use for over 50 years on a variety of different substrates. During this time they have undergone a continual process of optimisation.
The perfect combination of properties: Durable, strong, hardwearing, impact resistant, malleable, weather resistant, colour stable and highly resistant to micro-organism. They are designed with good vapour permeability to allow the building to breathe while still repelling liquid water. All renders are easy to apply and can be tinted from the StoColor System or matched to the colour of your choice, using the Sto spectrometer.
Coloured Self-Gauging Float Finish Renders: |
|||
 |
 |
 |
 |
StolitK 1.0mm |
StolitK 1.5mm |
StolitK 2.0mm |
StolitK 3.0mm |
StoTherm Classic System: |
|||
 |
 |
||
Stolit MP |
Stolit MP Natural |
The Perfect Finish: Competence in Colour
Download a technical specification for StoStucco from the list below. This specification is also integrated into the MasterSpec -4281 SL - Stucco. If you have any questions, please do not hesitate to contact us for technical support.
StoStucco is appraised by BRANZ. Click below to download the BRANZ Appraisal Certificate.
Download CAD or PDF details for your project. Use the interactive detail selector below - roll over the hot spots to find and download the appropiate detail:
SS-100
StoStucco Plaster System Cross Section
SS-101
StoStucco Typical Cavity Batten Layout
SS-104
StoStucco Lath Sheet Layout
SS-450
StoStucco Balustrade Parapet
SS-451
StoStucco Balastrade / Parapet - Building Wrap and Tape Position
Alternatively, select the link below to download a complete set of details below:
For a complete list of individual details, including CAD formats, please click here
Click here to hide details.
Disclaimer: These drawings have been issued as a guideline. The sequence work covers various building components, each trade is responsible to ensure their elements are fully installed, including all waterproofing / sealant / flashings as is applicable.
Last updated August 2011
